High-performance, ultra reliable and easy-to-use retransfer card printing solution
Built on seven generations of proven retransfer technology over the last 25 years, the FARGO HDP5000e ID card printer emerges as the next iteration of FARGO-branded, high-definition printing solutions, redefining the standards of reliability, usability, security and printing excellence.
Beyond its robust feature set, the HDP5000e simplifies and streamlines operation with its user-friendly SmartScreen™ interface — providing easy-to-understand notifications and helpful, walk-through prompts for setup, maintenance and troubleshooting.
Moreover, the HDP5000e offers the versatility to meet your card application needs today and in the future. The system’s flexible architecture lets you expand or reduce production capability instantly, with add-on dual-sided printing, encoding and lamination modules. For greater system capacity, an optional dual input card hopper lets you easily manage multiple card types and higher card volumes.
Ideal for medium-to-large corporations, universities, healthcare facilities and government agencies that need reliable retransfer printing technology to routinely issue superior-quality, high-definition cards and IDs, the FARGO HDP5000e offers:
Only one card printer offers seventh generation retransfer technology for every need — from sharp and vibrant photo ID cards to multifunctional, high-security ID badge and card applications, the customer-inspired FARGO HDP5000e is the solution of choice for superior image quality, ease-of-use and printer reliability.
| Sided Printing | Single or Dual |
|---|---|
| Print Method | HDP® Dye-Sublimation | Resin Thermal Transfer |
| Resolution | 300 dpi |
| Print Speed | Up to 27 seconds per card / 133 cards per hour (YMCK with transfer) |
| Accepted Card Sizes | CR-80 |
| Warranty | 4 years (printer); Lifetime (printhead) |
300dpi High Definition Printing (HDP) technology, for exceptional full color quality and durability. USB 2.0 and Ethernet with
internal print server.
Ribbon spools are now color-coded and cartridgeload for easier ribbon loading.
The HDP5000 is fully field-upgradeable to :
• Dual-sided printing
• Single- or dual-sided simultaneous lamination
• ISO magnetic stripe encoding
• Contact (ISO 7816) and contactless Chip Card read/encoding
The HDP5000’s new smart card encoders offer a first in the industry – one-wire printing
and encoding (contact and contactless) through a single USB or Ethernet connection.
| 96600 | Standard |
| 89640 | Dual-Sided printer |
| 96935 | Single Side Lamination module |
| 96936 | Dual-Sided Lamination module |
| 89001 | Dual-Sided Printing Module |
| 89270 | Dual-Card Input Hopper Module (2× 100 cards) |
| 89201 | Mag Encoding module |
| 89280 | OmniKey CardMan 5122 – 13.56 Contactless (Mifare) encoder |
| 89279 | OmniKey CardMan 5122 – 13.56 Contactless (Mifare) & Contact Smart Card encoder |
| D910536-01 | Card Hopper Cartridge (100 cards) |
| 89223 | Card Hopper with lock – (200 cards) |
| D910021-01 | Card Stacker (200 cards) |
| D910022 | Ribbon Cartridge |
| 89214 | Film Cartridge |
| 89213 | Key and Lock set |
| 86091 | Printhead |
| D920134 | Lam Cartridge – TOP |
| D920135 | Lam Cartridge – BOTTOM |
| 84500 | HDP film – thermal transfer/protection film (1500 prints) |
| 84501 | HDP Holographic film – thermal transfer/protection film (500 prints) |
| 84518 | K – Premium Resin Black (3000 prints) |
| 84511 | YMCK – Yellow, Magenta, Cyan, Black (500 prints) |
| 84512 | YMCKK – Yellow, Magenta, Cyan, 2 resin Black (500 prints) |
| 84514 | YMCFK – Yellow, Magenta, Cyan, Fluorescing, resin Black (500 prints) |
| 82615 | Thermal transfer Overlaminate film, thick. 6 μ, 500 cards |
| 82600 | PolyGuard polyester patch, thick. 15 μ, 250 cards |
| 82601 | PolyGuard polyester patch, thick. 25 μ, 250 cards |
| 82655 | PolyGuard polyester patch, thick. 25 μ, 250 cards — with Smart Chip cut-out |
| 82618 | Thermal transfer Overlam film, thick. 6 μ, 500 cards — with High Secure Orbit design Hologram |
| 82603 | PolyGuard polyester patch, thick. 15 μ, 250 cards — with High Secure Orbit design Hologram |
| 82604 | PolyGuard polyester patch, thick. 25 μ, 250 cards — with High Secure Orbit design Hologram |
| LC-1500 | Recombination Fees (moving existing master for new roll system) — holographic elements only |
| LC-1600 | Additional Visual Security Elements Fee — Mica Inks and UV Inks |
| LC-3500 | Origination Fees — Secure Random Image Placement |
| LC-9000 | Origination Fees — Secure Registered Image Placement |
| LC-12000 | Origination Fees — High-Secure Registered Image Placement |
| LC-14000 | Origination Fees — HDP Film (High-Secure Registered Image Placement) |
| — | PolyGuard polyester patch, thick. 15 or 25 μ, 250 cards — Whole or Half Patch for MagStripe |
| — | PolyGuard polyester patch, thick. 15 or 25 μ, 250 cards — with Smart Chip cut-out |
| — | Thermal transfer Overlam film, thick. 6 μ, 500 cards |
| — | HDP Custom Holographic film — thermal transfer/protection film (500 prints) |
| 89200 | Cleaning kit, incl. 2 Printhead Cleaning Swabs, 2 Clean Cards, 10 Adhesive Cards, 10 Pads |
| 86004 | Cleaning Rollers — 10 pcs |
Let’s talk about the perfect print solution for your business.
